Heavy Duty Aluminium Rotary Punching Machine with 8 Punch

About Heavy Duty Aluminium Rotary Punching Machine with 8 Punch

PPM- 8TR Aluminium Rotary Punching Machine for Cleat Fixing, Having 8 positions for different kind of profiles, Rotational base for operation from single position & Quick action Pneumatic punching by Cylinder actuation.

The PPM-8TR Aluminium 8 Position Rotary Punching Machine comes with the following features:

  Large Base for each Punch allows punching of bigger profile sections such as 3 track or 4 track sliding frames.

  Heavy Duty Pneumatic Cylinder can generate a punching force of 1.4 Ton, the machine is operated by foot padel with minimalistic settings.

  Specialised Guides to sustain work load during punching of heavier aluminium Sections.

  Any 8 Punches can be selected from the available series of Taalin Library however if required any new series punch can provided on demand.

  The position lock for any punch is achieved by easy to set push-pull device aided by smooth rotation of the base mount.

  Double stack with 4 position each allows working of variable range of aluminium profiles without the need to change of punch tool.

Technical Data:

  Compressed Air 7 Bar/100psi Air Consumption 200 Litre. Per cycle.

  Dimensions in mm (length, width, height) 400 x400x1350.

  Weight 210KG
