SGB 100M: Manual Glazing bead cutting saw comes with:2 x HSS saw blades, Pneumatic clamping,CuttingHeight Adjustment by hand wheel,One side supports 2.5-meter measuring length stop.
Features and Benefits:
The machine is standard equipped with completed bearing and measuring conveyors of 2.5 meter.
One fixed motor on the mobile carriage set at 45 to the workpiece support surface.
Verticaldual pneumatic clamping system with higher griping clamp pads.
Oneset of cutting saw blades HSS (High Speed Steel) with small blade having tapered teeth for trailing edge cutting.
Setting handle for forward &backward movement as well as for rotating the motor assembly mounted on the carrier.
The hand leverspulling rotating and pushing action cuts both side of beading in one cycle.
Care has been taken over the safety measures, both mechanical and electrical.
Power supply protects system from voltage overload.
Technical Data:
Saw blade diameter 200mm and 100mm.
Shaft diameter 32mm Voltage 380-415 v, 3 Phase, 3 amps .55 Kw of Rated Power
Compressed Air 7 Bar/100psi
Air Consumption 2 Litre. Per cycle
Dimensions (length, depth, height) 540 x 1000 x 1150mm
Weight 110KG.
Price:
![]() |
