UNIVERSAL DIGITAL GLAZING BEAD SAW MACHINE for Upvc Profile

About UNIVERSAL DIGITAL GLAZING BEAD SAW MACHINE for Upvc Profile

SGB 100 UD Digital Glazing bead cutting saw comes with: 4x HSS saw blades, Pneumatic clamping, Depth adjustable by Hand wheel, simultaneous dual bead cutting, universal rotary stops for all kind of beads, one side supports 2.5-meter Digital Conveyor and other side conveyor stand for full length bead support.

Features and Benefits:

         The machine is standard equipped with completed bearing and measuring conveyors of 2500 mmwhich is operated digitally by PLC Touch screen.

         The servo-controlled positioning with Planetary gears provides precise cutting with higher positional accuracy.

         Two bead pieces (depending on size) can be cut during a single cycle. The universal setting enables to cut all kind of beads without the need to change blocks.

         Suitable for fast cutting of 45-degree mitred beads only.

         Automatically trims the back leg (trailing edge) of the bead for seamless glass fitting.

         Two fixed, opposed blade motors on the mobile carriage set at 45 to the workpiece support surface in X configuration for cutting.

         4 cutting saw blades HSS (High Speed Steel) with trailing edge cutting by small blades.

         4 sets of Vertical pneumatic clamping systemwith specially designed flexible clamp pads to avoid inaccuracy due to slippage.

         6 positions rotary stop to allow cutting of all kind of beads with the need for any manual setting.

         Adjustable cutting speed with regulator on control panel.

         Care has been taken over the safety measures, both mechanical and electrical.

         Power supply protects system from voltage overload.

Technical Data:

  Saw blade diameter 200mm

  Shaft diameter 32mm Voltage 380-415 v, 3, 6 amps 1.1 Kw of Rated Power

  Compressed Air 7 Bar/100psi

  Air Consumption 4 Ltr. Per cycle

  Dimensions (length, depth, height) 540 x 1000 x 1150mm

  Weight 110KG

Options:

  profile-dependent limiters

  profile support: 3 m or 6 m

  RF device and related control panel
