Upvc Double Head Seamless Welding Machine

About Upvc Double Head Seamless Welding Machine

150mm Double Head Seamless Welding is designed to produce corner, variable angle joints in window and door profiles. It can do both 2mm (Normal) &.2mm(Seamless) welding, the fixed head has butt welding options as well. The machine has 3600mm as maximum length for welding with both head operation.

The WDS-6L Double Head Seamless Welding comes with the following features:

  This machine can do welding up-to a height of 155mm with standard welding burn-off as 6mm

   Utilises support plates which are adoptable to both magnetics as well asT nut mounted welding blocksto allow quick removal and refitting.

  No time-consuming hand wheel adjustments due to availability of pneumatics brakes on movable head which is activated by push button.

  All movements are made with smooth linear bearings and hardened steel shafts.

  The movable head is positioned by manual means which moves on linear bearings.

  LM guideways along with bearings gives free movements toheater plate for precisely aligned hassle-free welding. The mounting is designed in a user-friendly manner, having long life span.

  Adjustable knifes are provided to switch between 2mm (Normal) & .2mm (Seamless) welding.

  Designed to be easy to use and simple to maintain. Safety clamp, two hand control and individual pressor regulator for each head clamps.
