Manual Upvc V Cutting Machine

About Manual Upvc V Cutting Machine

SVC 10M: Manual V cutting saw comes with: 1 x TCT saw blades, Pneumatic clamping, Adjustable depth setting,One side supports 1.5-meter measuring length stop.

Features and Benefits:

  The machine is standard equipped with completed bearing and measuring conveyors (1+1.5 meters long each).

   One fixed blade motors on the mobile carriage set at 45 to the workpiece support surface.

  Profile depth adjustment by means of handwheel, pointer and mitre scale.

  Horizontal pneumatic clamping system

  The hand levers pulling rotating and pushing action cuts both side of beading in one cycle.

  Care has been taken over the safety measures, both mechanical and electrical

   Power supply protects system from voltage overload.

Technical Data:

  Saw blade diameter 250mm

  Shaft diameter 32mm Voltage 380-415 v, 3, 6 amps, .55 Kw of Rated Power

  Compressed Air 7 Bar/100psi

  Air Consumption 4 Litre. Per cycle

  Dimensions (length, depth, height) 540 x 1000 x 1150mm

  Weight 110KG.
